Echomax EM230BR Radar Reflector - 9 Inch

The middle sized Echomax Polyethylene models for sailing yachts, RIBs and motor cruisers. Fully tested by QinetiQ. Exceeds RORC/ORC requirement of 10m², but fails ISO 8729 by 2° per sector.

@+/-3°-20m² peak, 75% @2.5m², 100% @1.25m². Fits Blipper 210-7 mast brackets with same fixing centre of 545mm. Certified Ships Wheel mark for life boats and rescue craft.

Key Features

  • Increased Radar Cross Section
  • Increased Heel Response & High S Band Response
  • Increased 360° Response Cycle
  • Shipwheel mark for life boats and rescue craft
  • Height: 45cm
  • Diameter: 24.5cm
  • Fixing centres: 41cm
  • Fixing holes: 8mm Weight: 1.9kg
  • Weight: 1.9kg
  • Fits Firdell Blipper 210-7 Brackets
For mounting brackets see Website
