Ital Obi 1000 Windlass with Drum 1400W 12/24V 8/10mm Chain

Windlass made in anodized aluminium alloy, 12 volt 1400 watt with rope drum and chromed gypsy cover. Supplied with a rope-chain gypsy and equipped with a spring loaded rope pawl that guides/holds the rope in the gypsy, also has manual chain freefall release, supplied with a 8/10 mm gypsy the windlass is also supplied with a built-in chain counter sensor and control box.

Specification:

  • Electric Motor: 1400 Watt
  • Motor Supply Voltage: 1224 Volt
  • Chain: 8/10mm
  • Maximum Pull: 1200 KG
  • Maximum Chain Speed: 26 Mt min
  • Current Absorption: 12V 130A, 24V 70 A
  • Weight: 17.6 Kg

Models

  • Obi 1000 with Drum 12V 8mm Chain
  • Obi 1000 with Drum 12V 10mm Chain
  • Obi 1000 with Drum 24V 8mm Chain
  • Obi 1000 with Drum 24V 10mm Chain
